Document image processing SDK

1
using GdPictureImaging gdpictureImaging = new GdPictureImaging();
2
// Load the image from a file.
3
int imageId = gdpictureImaging.CreateGdPictureImageFromFile(@"C:/temp/source.png");
4
// Deskew the image.
5
gdpictureImaging.AutoDeskew(imageId, 10);
6
// Save the output in a new image.
7
gdpictureImaging.SaveAsPNG(imageId, @"C:/temp/output.png");
8
gdpictureImaging.ReleaseGdPictureImage(imageId);

1
Using gdpictureImaging As GdPictureImaging = New GdPictureImaging()
2
    ' Load the image from a file.
3
    Dim imageId As Integer = gdpictureImaging.CreateGdPictureImageFromFile("C:/temp/source.png")
4
    ' Deskew the image.
5
    gdpictureImaging.AutoDeskew(imageId, 10)
6
    ' Save the output in a new image.
7
    gdpictureImaging.SaveAsPNG(imageId, "C:/temp/output.png")
8
    gdpictureImaging.ReleaseGdPictureImage(imageId)
9
End Using

1
using GdPictureImaging gdpictureImaging = new GdPictureImaging();
2
// Load the image from a file.
3
int imageId = gdpictureImaging.CreateGdPictureImageFromFile(@"C:/temp/source.png");
4
// Check if the image has inverted colors.
5
bool isNegative = gdpictureImaging.IsNegative(imageId);
6
if (isNegative)
7
{
8
    // Reverse the colors.
9
    gdpictureImaging.FxNegative(imageId);
10
    gdpictureImaging.SaveAsPNG(imageId, @"C:/temp/output.png");
11
}
12
// Release the image resource.
13
gdpictureImaging.ReleaseGdPictureImage(imageId);

1
Using gdpictureImaging As GdPictureImaging = New GdPictureImaging()
2
    ' Load the image from a file.
3
    Dim imageId As Integer = gdpictureImaging.CreateGdPictureImageFromFile("C:/temp/source.png")
4
    ' Check if the image has inverted colors.
5
    Dim isNegative As Boolean = gdpictureImaging.IsNegative(imageId)
6
    If isNegative Then
7
        ' Reverse the colors.
8
        gdpictureImaging.FxNegative(imageId)
9
        gdpictureImaging.SaveAsPNG(imageId, "C:/temp/output.png")
10
    End If
11
    ' Release the image resource.
12
    gdpictureImaging.ReleaseGdPictureImage(imageId)
13
End Using

1
using GdPictureImaging gdpictureImaging = new GdPictureImaging();
2
// Load the image from a file.
3
int imageId = gdpictureImaging.CreateGdPictureImageFromFile(@"C:/temp/source.png");
4
// Fix thick characters.
5
gdpictureImaging.FxBitonalErode8(imageId);
6
// Save the output in a new image.
7
gdpictureImaging.SaveAsPNG(imageId, @"C:/temp/output.png");
8
gdpictureImaging.ReleaseGdPictureImage(imageId);

1
Using gdpictureImaging As GdPictureImaging = New GdPictureImaging()
2
    ' Load the image from a file.
3
    Dim imageId As Integer = gdpictureImaging.CreateGdPictureImageFromFile("C:/temp/source.png")
4
    ' Fix thick characters.
5
    gdpictureImaging.FxBitonalErode8(imageId)
6
    ' Save the output in a new image.
7
    gdpictureImaging.SaveAsPNG(imageId, "C:/temp/output.png")
8
    gdpictureImaging.ReleaseGdPictureImage(imageId)
9
End Using

1
using GdPictureImaging gdpictureImaging = new GdPictureImaging();
2
// Load the image from a file.
3
int imageId = gdpictureImaging.CreateGdPictureImageFromFile(@"C:/temp/source.png");
4
// Remove salt-and-pepper noise.
5
gdpictureImaging.FxBitonalDespeckle(imageId, false);
6
// Save the output in a new image.
7
gdpictureImaging.SaveAsPNG(imageId, @"C:/temp/output.png");
8
gdpictureImaging.ReleaseGdPictureImage(imageId);

1
Using gdpictureImaging As GdPictureImaging = New GdPictureImaging()
2
    ' Load the image from a file.
3
    Dim imageId As Integer = gdpictureImaging.CreateGdPictureImageFromFile("C:/temp/source.png")
4
    ' Remove salt-and-pepper noise.
5
    gdpictureImaging.FxBitonalDespeckle(imageId, False)
6
    ' Save the output in a new image.
7
    gdpictureImaging.SaveAsPNG(imageId, "C:/temp/output.png")
8
    gdpictureImaging.ReleaseGdPictureImage(imageId)
9
End Using
